NFLG JS4000D Mixer And Parts

Models:NFLG JS4000D.0(XD3.0)

#!trpst#trp-gettext data-trpgettextoriginal=1982#!trpen#UGS :#!trpst#/trp-gettext#!trpen# #!trpst#trp-gettext data-trpgettextoriginal=1977#!trpen#ND#!trpst#/trp-gettext#!trpen# #!trpst#trp-gettext data-trpgettextoriginal=1983#!trpen#Catégories :#!trpst#/trp-gettext#!trpen# , #!trpst#trp-gettext data-trpgettextoriginal=1984#!trpen#Étiquettes :#!trpst#/trp-gettext#!trpen# , ,

Here is a description of the NFLG JS4000D Mixer And Parts

NO. Specification Item code Unit weight (Kg) Qty Unit. Total weight (Kg)
1 Feed Long Arm JS4000XD.5.1-2 66.2 14 Pcs 926.8
2 Return Long Arm JS4000XD.5.5-2 66.2 2 Pcs 132.4
3 Side Feed Arm JS4000XD.5.7-3 58.8 2 Pcs 117.6
4 Side Return Arm JS4000XD.5.8-3 58.8 2 Pcs 117.6
5 Feed Short Arm JS4000XD5.2-2 40 16 Pcs 640
6 Return Short Arm JS4000XD5.6-2 40 4 Pcs 160
7 Hexagon Socket Head Screw M30*120GB/T70.1 80 Set 0
8 Side Feed Blade A JS4000XD.5.2-1 25.2 2 Pcs 50.4
9 Side Return Blade A JS4000XD.5.5-1 25.6 2 Pcs 51.2
10 Side Feed Blade B JS4000XD.5.3-2 13.6 2 Pcs 27.2
11 Side Return Blade B JS4000XD.5.4-2 13.4 2 Pcs 26.8
12 Feed Blade (Long) JS4000XD.5.3-1 23.5 14 Pcs 329
13 Return Blade (Long) JS4000XD.5.5-1 23.5 2 Pcs 47 。
14 Feed Blade (Short) JS4000XD.5.4-1 10.8 14 Pcs 151.2
15 Return Blade (Short) JS4000XD.5.6-1 10.8 2 Pcs 21.6
16 Small Side Blade (Positive) JS4000XD.5.2-1 13.8 2 Pcs 27.6
17 Small Side Blade (Negative) JS4000XD.5.7-1 13.8 2 Pcs 27.6
18 Blade Bolt M16*1.5*65 80 Set 0
19 Blade Bolt M18*1.5*65 40 Set 0
20 Curved Lining 1 JS4000XC.3-1 6.92 112 Pcs 775.04
21 Curved Lining 2 JS4000XC.3-2 6.56 32 Pcs 209.92
22 End Lining 1 JS4000XC.3-3 21.4 8 Pcs 171.2
23 End Lining 2 JS4000XC.3-4 20.3 4 Pcs 81.2
24 End Lining 3 JS4000XC.3-5 20.3 4 Pcs 81.2 。
25 End Lining 4 JS4000XC.3-6 18.8 4 Pcs 75.2
26 End Lining 5 JS4000XC.3-7 18.8 4 Pcs 75.2
27 End Lining 6 JS4000XC.3-8 10.4 16 Pcs 166.4
28 Discharge Door Flange Seal Plate A JS2250XC2.3-5 11.2 2 Pcs 22.4
29 Discharge Door Flange Seal Plate B JS2250XC2.3-6 8 12 Pcs 96
30 Curved Flange A JS4500C2.3-3 23 2 Pcs 46
31 Curved Flange B JS4500C2.3-4 23 2 Pcs 46
32 Plate Screw M4*1.5*50 244 Set 0
Total 4 730 4699.76



As a leading manufacturer, we pride ourselves on providing original replacements and durable components that surpass industry standards.

When we talk about original replacement, we mean components designed to seamlessly fit and function within your JS4000D mixer. Our commitment to precision engineering ensures that each blade, mixing arm, and liner maintains the exact specifications of the original parts, guaranteeing optimal performance and compatibility.

In addition to original replacements, we offer aftermarket solutions that provide flexibility without compromising quality. These components undergo rigorous testing to meet the high standards set by the industry. Our aftermarket options not only broaden your choices but also deliver reliable performance, making them a cost-effective solution for your mixer maintenance needs.

Mixing Parts

Arm Counterpart, Arm Protector, End Liners, Mixing Arm, Mixing Blade, Wall Liners

Statement

All brand names, part numbers, model numbers and descriptions are used for identification purposes only, they are owned by the Genuine company.We provide alternative aftermarket  parts for subject machines according to the parts number and machine models. All parts are manufactured and warranted by Mining against our own drawings, Mining has no association of OEM with above mentioned brands.
